Six independent chambers
Isolated culture spaces prevent cross-contamination and parameter drift when adjacent lids are opened.
Series: MIRI®
Esco Lifesciences
MIRI® Multiroom Incubator
Six-chamber dry multiroom incubator for independent embryo culture
Embryology EquipmentIncubatorsEquipment
- Model:
- MRI-6A10-8 · MRI-6A10-9
- Item code:
- 2070047
1 / 3Specifications
- Item code
- 2070047
Order codes (8)
- Chambers
- 6 independent (dry)
- Dimensions (W × D × H)
- 700 × 585 × 165 mm
- Net weight
- 40 kg
- Power
- 300 W · 115 V or 230 V
Dry model (MRI-6A10). Humidified variant: MIRI® Humidity Multiroom. CO₂ <2 L/h and N₂ <12 L/h under normal closed-lid conditions at typical set-points.
Workflow: Embryo Culture
Overview
The MIRI® Multiroom Incubator is Esco Medical’s six-chamber dry benchtop system for IVF embryo culture. Each chamber operates independently so opening one lid does not disturb neighboring cultures. Heated lids (37.2 °C set point) work with optimized heating plates to deliver accurate 37.0 °C at the embryo level, with fast temperature and gas recovery after access. Pure N₂ and CO₂ or premixed gas can be used; pure gases enable cost-effective recirculation and flexible CO₂/O₂ set-points. The incubator accepts Falcon®, Nunc™, Vitrolife, LifeGlobal®, Nipro™, SparMED Oosafe®, and plain dishes via dedicated heating plates. Optional MIRI® Data Logger, stacking frames, VOC/HEPA filters, and MIRI® GA validation complete the workflow.
Applications
- IVF and ART embryo culture (dry environment)
- Multi-patient scheduling with six isolated chambers
- Laboratories prioritizing footprint and independent chamber access
Product features
Heated lid and fast recovery
Top and bottom heating maintain embryo-level temperature with rapid recovery after chamber access.
Superior recirculating gas system
Tri-gas mixing with VOC/HEPA filtration and UV sterilization minimizes consumption while keeping air clean.
Flexible dish compatibility
Heating optimization plates for major IVF culture dish formats and plain dishes.
External validation ready
Gas sampling ports and PT-1000 sensors per chamber; compatible with MIRI® GA validation unit.
MIRI® Data Logger (optional)
Monitor temperature, gas, pressure, and alarms with graphs, reports, and multi-incubator overview.
